BO Dynamics DIAMONDBACK DB15 AP306 7" M4/AR-15 AEG

BO Dynamics
Code:
£169.99
  • M-LOK handguard
  • Suppressor included
  • Lots of real steel trademarks!

This BO Dynamics DIAMONDBACK DB15 AP306 7" M4/AR-15 AEG is compact and lightweight, it is constructed from a high-density, lightweight polymer and is scratch-resistant, great for newcomers who are still trying to get to grips with the skirmish lifestyle. It also features a Helios suppressor or compensator so you can find your favourite look or gameplay style. This package also includes an 11.1V crane battery, a balance charger, tools and 2x 20mm Picatinny rail sections. This is a brilliant deal for newer players as it includes everything they need to shoot this AEG straight out of the box!

This rifle is also equipped with a MOSFET that allows for programmable firing modes, this is an amazing feature for the relatively low price and gives beginner players a chance to experiment with different firing modes, additionally, the MOSFET will also protect your rifle from short circuits and burnouts.

If you're a fan of staying swift, sneaking around the battlefield and surprising unsuspecting foes, then the BO Dynamics DIAMONDBACK DB15 AP306 7" M4/AR-15 AEG is perfect for you!

Full description

Description

This AEG has full licensing from Diamondback Firearms, the real steel American gun company. It is a short assault rifle, based loosely on Diamondback's popular DB15 series of assault rifles. This replica shares some features with the real steel rifles, such as the Diamondback markings that feature all over the rifle. Complete your American loadout with a rifle that features genuine American firearm trademarks, ensuring ultimate realism!

Starting at the tip of the alloy outer barrel we can find an alloy Helios™ suppressor, which mounts to the 14mm CCW male threading hidden underneath. The Helios™ logo is a nice touch as it adds to the premium feel of this suppressor, and the trademark is sure to draw eyes whilst out on the battlefield. Also included in the box is a Helios™ compensator if you prefer a shorter more compact style, the compensator features 24mm threading on it for an aftermarket tracer unit or a suppressor.

Surrounding the 7" outer barrel we have the polymer M-LOK rail handguard, which is styled after the real steel and gives the rifle an authentic look. The M-LOK attachment interface is functional and allows the 2 included Picatinny rail sections to be moved around and mounted anywhere at the 3, 6 or 9 o'clock position on the handguard, aftermarket M-LOK accessories can also be attached to these sections. On this polymer handguard, we can see our first Diamondback trademarks, sitting at the 3 and 9 o'clock positions. These have been laser engraved into the handguard and look incredible.

The 12 o'clock position of the handguard provides a full-length 20mm Picatinny rail which integrates seamlessly with the receiver rail to allow for longer optical sights to be used or red dot sight magnifier combos. As it arrives, the DB15 AP306 is equipped with a pair of flip-up aperture iron sights, the front sight has adjustable elevation and the rear sight has adjustable windage. The front sight has a rotary adjuster just under the post and the rear sight has turrets on either side which can be twisted to move the sight left and right. The sights can be deployed by flipping them up, which will snap the sights into the upright position. To stow the sights, simply push them back down and they will click into place. The rear sight has two hole sizes that can be changed on the move so you can engage your opponents at any range.

Moving rearward we reach the receiver, which has a familiar M4/AR-15 layout and is constructed from high-density polymer. The fire selector is ambidextrous, located on both sides of the AEG, sitting directly above the pistol grip to provide fast and easy access. The fire selector has a 90-degree throw between modes and makes a satisfying click into place, it is quick to operate and the tactile click ensures you won't accidentally knock it and end up in the wrong fire mode without realising it. Each fire mode is indicated with recessed markings reading SAFE-SEMI-AUTO.

Located dead centre on the left side of the receiver we find a dummy bolt release catch which doesn't have a function on this Airsoft AEG but is included anyway to keep the externals looking realistic. The bolt release perfectly pairs with the Diamondback trademarks to make this AEG look extremely authentic and avoid the tell-tale signs that this is an Airsoft gun and not the real deal.

The magazine release is on the right side of the magazine well and is perfectly positioned to be pressed with the trigger finger when it's time to reload. The design is a unique rectangular shape and the surface of the mag release is textured to provide the necessary gripping qualities. Slightly rearwards of this mag release is another laser-engraved Diamondback trademark, further solidifying the realism that this AEG displays.

Pulling back the extended charging and letting it retract pops open the steel dust cover. Immediately, the 5.56 NATO marking is noticeable on the inside of the dust cover/mock ejection port cover. These markings denote the ammo type that would be shot from a real steel variant of this rifle. On the mock bolt plate, there is an additional trademark, this is the Diamondback logo and is bright white which brilliantly contrasts the rest of the metallic black port.

The adjustable HOP-up unit is located inside this mock ejection port. This device allows you to adjust the amount of backspin applied to your BBs and tune the DB15 AP306 for your ammo weight of choice, looking for the flattest possible trajectory. The Rotary HOP-up adjuster can be accessed by holding the charging handle back and keeping the mock bolt plate retracted. The rotary HOP-up design is known as the latest and greatest for M4 AEGs, it retains the HOP-up settings better than previous gear adjustment styles.

The pre-installed pistol grip is an exclusive Bo Manufacturer grip that offers plenty of positive grip when handling the rifle. It is a modern ergonomic design with indents at either side of the top for your thumb to comfortably sit on for both left and right-hand shooters. It features a rough texture on the left and right sides for a good grip, and the BO Dynamics insignia is present on the rear of the grip. The trigger is known as the CNC Type A Flat trigger, offering a flat serrated front surface with a short finger ledge, ideal for rapid double taps. It is also skeletonised to add to the modern look and shave off precious grams to make the rifle even lighter.

Following the receiver, we reach the PDW-style buffer tube. It is constructed from polymer and provides 3 positions of adjustment. To adjust the stock position, press down both buttons located on either side of the stock then slide the stock to your desired position. There is an additional Diamondback trademark featured along the left PDW stock bar. The butt plate is constructed from high-density polymer and features a skeletonised design, it provides comfort and security when wearing full-body gear and operating from modern shooting stances. The buffer tube has a raised cheek pad for improved comfort. A Diamondback logo can be found on the butt plate, the real steel branding makes this AEG look genuine!

The battery compartment is located within the PDW buffer tube and can be accessed by removing the stock. To do this, press the buttons to adjust the stock then slide it off, afterwards, you can press the tab on the top of the buffer tube and remove the cap to access the Deans style connector. The BO Dynamics DIAMONDBACK DB15 AP306 7" M4/AR-15 AEG has an included 11.1V 1000mAH crane-style battery included. This battery is an extremely tight fit due to the small size of a PDW buffer tube. Be careful when installing the battery, do not crush any of the battery cells and do not damage any of the wires.

This AEG features some good internals for a rifle of this price range. It includes a version 2 gearbox with 18:1 ratio steel gears on 8mm ball bearing bushings, durable maple leaf HOP-up rubber, a 6.03mm tightbore inner barrel, a programmable electronic trigger unit and an integrated MOSFET unit that keeps your electronics in check from short circuits and burnouts. The programmable electronic trigger modes are full-auto, semi, a burst of 2, 3, 4 and 5 shots (pressing the trigger will fire the programmed number of shots) and a Binary / Double tap mode.

For those who are relatively fresh to the battlefield or maybe an experienced Airsofter looking for a lightweight backup platform, the BO Dynamics DIAMONDBACK DB15 AP306 7" M4/AR-15 AEG is perfect for your needs. It also includes lots of additional accessories along with the rifle, plenty of gear for a low price! With its elite looks, good preinstalled internals, plenty of trademarks from Diamondback and its solid lightweight polymer construction, the DB15 AP306 is a great versatile platform for all players!

Features

  • 6.03mm Tightbore inner barrel - Great accuracy potential
  • Full Diamondback licensing - Authentic trademarks
  • Helios™ suppressor and compensator included
  • 14mm CCW Male threaded outer barrel - Tracer/suppressor ready
  • Flip-up iron sights pre-installed - Mounted to the top rail
  • M-LOK style handguard - Includes 20mm rail sections
  • Ambidextrous fire selector and pistol grip
  • Extended charging handle latch - Easy access to the HOP-up unit for adjustment
  • 20mm Picatinny railed receiver - Ready for a red dot sight or rifle scope
  • Rotary adjustable HOP-up unit - Easy to adjust in fine increments, holds its setting well long-term
  • 3-Position PDW buffer tube - Adjust the stock to suit your body type
  • Ergonomic pistol grip with reduced grip angle - Great for modern shooting stances, very comfy
  • Reinforced version 2 gearbox
    • Maple leaf HOP-up rubber
    • Quick change spring guide
    • Steel 18:1 gearset
    • 8mm Bushings
  • Rear wired - Deans connector - Included 11.1V 1000mAH crane battery

Package Includes

  • BO Dynamics DIAMONDBACK DB15 AP305 7" M4/AR-15 AEG
  • Helios™ suppressor
  • Helios™ compensator
  • 2x 20mm Picatinny rail sections
  • 120rnd mid-cap magazine
  • BO Dynamics 11.1V 1000mAH crane battery
  • BO Dynamics Lipo balance charger
  • Cleaning rod
  • QD sling point
  • Tools
  • Deans to Mini Tamiya

Specification

General

Weapon Construction External
Weapon Type
Assault Rifle
Over 18 Only Icon
Over 18
Yes
Icon UKARA - United Kingdom Airsoft Retailer Association
Defence / UKARA Required
Yes, No,
FPS Icon
FPS (Feet Per Second), using 0.20g BB
Approx. 280fps ± 10%, using 0.20g BB
Site Legal Icon
Site Legal, using 0.20g BB
Yes
Screwdriver Icon
Pre-Built
Yes
Package
Included Items
  • Magazine
  • Cleaning Rod
  • Charger
  • Tools
  • 20mm RIS/RAS Rail Sections
  • QD Sling Point
  • Deans to Mini-Tamiya Connector
  • Screw Set
  • Compensator
  • 11.1V 25c 1000mAH Nunchuck w/ Deans
Skill Level Icon
User Skill Level
Regular Player
Patrol Base - Warning Icon
Warnings
Li-Po - Never Leave Charging Unattended
Li-Po - Only Use Approved Chargers
Li-Po - Charge in a Fire Safe Area

Weight and Dimension

Weight KG Icon
Weight (KG)
Approx. 2kg
Weapon Length Collapsed
Length (Collapsed)
77cm
Weapon Length Extended
Length (Extended)
87cm

Construction

Colour Wheel Greyscale
Primary Colour
Black
Construction Icon
Construction
Alloy outer barrel, buffer tube and suppressor. Polymer handguard, receiver, stock, grip, iron sights. Steel dust cover, screws and pins
Weapon Construction External
External Construction
Polymer
Alloy
Gearbox Icon
Internal Construction
Polymer
Alloy
Steel

Weapon Specific

Power Source Icon
Powered By
Electric
Blowback Icon
Blowback
None
Weapon Platform
AR, M4 / AR-15 / M16, Assault Rifle,
Magazine Style Icon
Magazine Style
Long Gun Magazine, Assault Rifle, M4 / AR Platform,
Fire Select Icon
Fire Selector
PatrolBase | Fire Select Safe
Safe
Patrol Base | Fire Select - Semi Automatic
Semi Automatic
Patrol Base | Full Automatic
Full Automatic
Programmable
Weapon Safety Features Icon
Safety Features
Trigger Disconnect
Shooter Configuration Icon
Shooter Configuration
Right Handed
Weapon Configuration Icon
Weapon Configuration
Standard
Weapon Scale Icon
Weapon Scale
1:1
Suggested BB Weight
0.25g

Hop-Up

Hop-Up Unit Icon
Hop-Up Unit
Yes
Hop-Up Unit Adjuster Icon
Hop-Up Adjuster
Rotary
Hop-Up Unit Location Icon
Hop-Up Location
Behind the mock bolt, accessible when the charging handle is pulled and held back.

Furniture

Weapon Furniture Icon
Furniture
  • Suppressor
  • Flip-Up Ironsights
  • Ambidextrous Charging Handle
  • Ambidextrous Fire Selector
  • Ergonomic Pistol Grip
  • Adjustable Stock
  • Adjustable Ironsights
  • Extended Charging Handle
  • sling point
  • PDW stock
  • M-LOK Handguard
  • Aperture iron sights
Rail System Icon
Rail System
20mm Railed Receiver, M-LOK Rail system,
Icon Stock Positions
Stock Setting
Sliding
Weapon Length Extended
Stock Positions
3 Position
Sight Type Icon
Sight Type
Iron Sights , Aperture Iron Sight,
Sling Plate Icon
Sling Options
Stock

Barrel

Outer Barrel Length (in)
7''
Icon Thread Type
Outer Barrel Thread Type
Male
Icon Thread Direction
Outer Barrel Thread Direction
CCW (Counter Clockwise)
Outer Barrel Thread Size
14mm
Inner Barrel Diameter
6.03mm
Inner Barrel Length
215mm

Magazine Specific

Magazine Type
Medium Capacity , AEG,
Magazine BB Capacity
Approx. 120 Rounds
Magazine BB Fill Method
Speed Loader
Magazine BB Fill Location
Top

Electric Gun Specific Information

Gearbox
Gearbox Icon
Gearbox Version
V2 Gearbox
Wiring Icon
Gearbox Wiring
Rear Wired
Digital Trigger Icon
Gearbox Electronic Trigger
Yes
Motor
Airsoft Motor Icon
Motor Type
Standard
Battery Specific
Battery Connector
Patrol Base | Icon | Deans
Deans
,
Deans To Mini Tamiya
Deans To Mini Tamiya Adaptor
,
Included Battery
Battery Configuration
Crane
Battery Type
Li-Po
Battery Voltage
11.1V
Battery Amperage
1000mAh
Compatible Battery
Compatible Battery Type
Li-Po
Compatible Battery Configuration
Crane
Compatible Battery Voltage
11.1v

Product Testing Data

Notepad Icon
Test Description
280FPS +/- 10%
Notepad Icon
Tested Using
ASG Blaster 0.20g BBs
Notepad Icon
Test Date
10/07/2024

Further Information

FALCON EFCS MOSFET

Please note that the gun's EFCS system is only compatible with LiPo Batteries, and is not compatible with LiFe or NiMh batteries.

Please note that both binary fire and burst modes can be set, as binary fire is applied to semi, and 1-5 fire mode is applied to full auto.

FALCON EFCS Protection Feature

Gearbox Protection

When the current is too high or abnormal the power supply on the EFCS will disconnect to protect the motor and battery, and the motor will vibrate three times.

If the battery's voltage is too high the EFCS power supply will automatically disconnect and the motor will vibrate twice.

Battery Protection

The FALCON EFCS has an operating voltage between 6-13v. If the voltage is too low or too high the power supply will be cut. If the voltage of your battery is too low, the FALCON will notify the user via 5 vibrations, then cut the power to protect your battery.

Vibration Description

  • 1 - Power On
  • 2 - System Error
  • 3 - Voltage too high
  • 5 - Low Voltage

Falcon Electronic Fire Control System

1-5 Shot Mode

  • Set the fire selector to SAFE.
  • Pull the trigger and hold for 3 seconds to enter programming mode, and release when the motor makes a sound.
  • Pull the trigger once and release it to enter 1-5 shot programming mode. Release it when the motor makes a sound.
  • Pull the trigger 1-5 times depending on the amount of shots you want a single trigger pull to make.
  • Set the fire select to full auto.

Trigger Sensitivity

  • Set the fire selector to SAFE.
  • Pull the trigger and hold for 3 seconds to enter programming mode, and release when the motor makes a sound.
  • Pull the trigger twice and release it to enter sensitivity programming mode. Release it when the motor makes a sound.
  • Pull the trigger between 1-3 times for different levels of sensitivity.
    • 1 - Highest Sensitivity
    • 2 - Standard Sensitivity
    • 3 - Low Sensitivity

Binary Fire Mode

  • Set the fire selector to SAFE.
  • Pull the trigger and hold for 3 seconds to enter programming mode, and release when the motor makes a sound.
  • Pull the trigger three times and release it to enter binary fire programming mode. Release it when the motor makes a sound.
  • Set the fire selector to semi-auto
  • Repeat the same process to disable binary fire

Reset to Default

  • Set the fire selector to SAFE.
  • Pull the trigger and hold for 5 seconds to reset all settings.

Size guide

Joule Charts

Special Instructions

These table can be used as a reference to see if the BB weight you are using will be over acceptable Joulage limits at some Airsoft Sites in the UK. To check if the weight can be used chrono your weapon using the BB you intend to use, and then compare it to the chart.

FPS, Power and Joule Limits can vary from site to site, so please get in touch with where you're going to play with in advance to avoid disappointment.

Suggested limits are based on Joulage Limit rules used Halo Mill: Proving Grounds, with a 350fps limit for Automatic Replicas, 400fps for Semi-Automatic Replicas, and 500fps for Bolt Action Replicas.

Tap the tabs below to open the relevant chart for your replica.

Suggested limits are based on Joulage Limit rules used Halo Mill: Proving Grounds, and is the equivalent of 350fps, using 0.20g BB resulting in an upper limit of 1.14j.

Velocity BB Weight (Grams)
FPS 0.20 0.25 0.28 0.30 0.32 0.36 0.40 0.43 0.45 0.50
250 0.58 0.73 0.81 0.87 0.93 1.05 1.16 1.25 1.31 1.45
260 0.63 0.79 0.88 0.94 1.00 1.13 1.26 1.35 1.41 1.57
270 0.68 0.85 0.95 1.02 1.08 1.22 1.35 1.46 1.52 1.69
280 0.73 0.91 1.02 1.09 1.17 1.31 1.46 1.57 1.64 1.82
290 0.78 0.98 1.09 1.17 1.25 1.41 1.56 1.68 1.76 1.95
300 0.84 1.05 1.17 1.25 1.34 1.51 1.67 1.80 1.88 2.09
310 0.89 1.12 1.25 1.34 1.43 1.61 1.79 1.92 2.01 2.23
320 0.95 1.19 1.33 1.43 1.52 1.71 1.90 2.05 2.14 2.38
325 0.98 1.23 1.37 1.47 1.57 1.77 1.96 2.11 2.21 2.45
328 1.00 1.25 1.40 1.50 1.60 1.80 2.00 2.15 2.25 2.50
330 1.01 1.26 1.42 1.52 1.62 1.82 2.02 2.18 2.28 2.53
335 1.04 1.30 1.46 1.56 1.67 1.88 2.09 2.24 2.35 2.61
340 1.07 1.34 1.50 1.61 1.72 1.93 2.15 2.31 2.42 2.68
345 1.11 1.38 1.55 1.66 1.77 1.99 2.21 2.38 2.49 2.76
350 1.14 1.42 1.59 1.71 1.82 2.05 2.28 2.45 2.56 2.85
355 1.17 1.46 1.64 1.76 1.87 2.11 2.34 2.52 2.63 2.93
360 1.20 1.51 1.69 1.81 1.93 2.17 2.41 2.59 2.71 3.01

Suggested limits are based on Joulage Limit rules used at Halo Mill: Proving Grounds, and is the equivalent of 400fps, using 0.20g BB resulting in an upper limit of 1.49j.

Velocity BB Weight (Grams)
FPS 0.20 0.25 0.28 0.30 0.32 0.36 0.40 0.43 0.45 0.50
250 0.58 0.73 0.81 0.87 0.93 1.05 1.16 1.25 1.31 1.45
260 0.63 0.79 0.88 0.94 1.00 1.13 1.26 1.35 1.41 1.57
270 0.68 0.85 0.95 1.02 1.08 1.22 1.35 1.46 1.52 1.69
280 0.73 0.91 1.02 1.09 1.17 1.31 1.46 1.57 1.64 1.82
290 0.78 0.98 1.09 1.17 1.25 1.41 1.56 1.68 1.76 1.95
300 0.84 1.05 1.17 1.25 1.34 1.51 1.67 1.80 1.88 2.09
310 0.89 1.12 1.25 1.34 1.43 1.61 1.79 1.92 2.01 2.23
320 0.95 1.19 1.33 1.43 1.52 1.71 1.90 2.05 2.14 2.38
330 1.01 1.26 1.42 1.52 1.62 1.82 2.02 2.18 2.28 2.53
340 1.07 1.34 1.50 1.61 1.72 1.93 2.15 2.31 2.42 2.68
350 1.14 1.42 1.59 1.71 1.82 2.05 2.28 2.45 2.56 2.85
360 1.20 1.51 1.69 1.81 1.93 2.17 2.41 2.59 2.71 3.01
370 1.27 1.59 1.78 1.91 2.03 2.29 2.54 2.73 2.86 3.18
380 1.34 1.68 1.88 2.01 2.15 2.41 2.68 2.88 3.02 3.35
390 1.41 1.77 1.98 2.12 2.26 2.54 2.83 3.04 3.18 3.53
400 1.49 1.86 2.08 2.23 2.38 2.68 2.97 3.20 3.34 3.72
410 1.56 1.95 2.19 2.34 2.50 2.81 3.12 3.36 3.51 3.90

Suggested limits are based on Joulage Limit rules used at Halo Mill: Proving Grounds, and is the equivalent of 500fps, using 0.20g BB resulting in an upper limit of 2.32j.

Velocity BB Weight (Grams)
FPS 0.20 0.25 0.28 0.30 0.32 0.36 0.40 0.43 0.45 0.50
250 0.58 0.73 0.81 0.87 0.93 1.05 1.16 1.25 1.31 1.45
260 0.63 0.79 0.88 0.94 1.00 1.13 1.26 1.35 1.41 1.57
270 0.68 0.85 0.95 1.02 1.08 1.22 1.35 1.46 1.52 1.69
280 0.73 0.91 1.02 1.09 1.17 1.31 1.46 1.57 1.64 1.82
290 0.78 0.98 1.09 1.17 1.25 1.41 1.56 1.68 1.76 1.95
300 0.84 1.05 1.17 1.25 1.34 1.51 1.67 1.80 1.88 2.09
310 0.89 1.12 1.25 1.34 1.43 1.61 1.79 1.92 2.01 2.23
320 0.95 1.19 1.33 1.43 1.52 1.71 1.90 2.05 2.14 2.38
330 1.01 1.26 1.42 1.52 1.62 1.82 2.02 2.18 2.28 2.53
340 1.07 1.34 1.50 1.61 1.72 1.93 2.15 2.31 2.42 2.68
350 1.14 1.42 1.59 1.71 1.82 2.05 2.28 2.45 2.56 2.85
360 1.20 1.51 1.69 1.81 1.93 2.17 2.41 2.59 2.71 3.01
370 1.27 1.59 1.78 1.91 2.03 2.29 2.54 2.73 2.86 3.18
380 1.34 1.68 1.88 2.01 2.15 2.41 2.68 2.88 3.02 3.35
390 1.41 1.77 1.98 2.12 2.26 2.54 2.83 3.04 3.18 3.53
400 1.49 1.86 2.08 2.23 2.38 2.68 2.97 3.20 3.34 3.72
410 1.56 1.95 2.19 2.34 2.50 2.81 3.12 3.36 3.51 3.90
420 1.64 2.05 2.29 2.46 2.62 2.95 3.28 3.52 3.69 4.10
430 1.72 2.15 2.40 2.58 2.75 3.09 3.44 3.69 3.86 4.29
440 1.80 2.25 2.52 2.70 2.88 3.24 3.60 3.87 4.05 4.50
450 1.88 2.35 2.63 2.82 3.01 3.39 3.76 4.04 4.23 4.70
460 1.97 2.46 2.75 2.95 3.15 3.54 3.93 4.23 4.42 4.91
470 2.05 2.57 2.87 3.08 3.28 3.69 4.10 4.41 4.62 5.13
480 2.14 2.68 3.00 3.21 3.42 3.85 4.28 4.60 4.82 5.35
490 2.23 2.79 3.12 3.35 3.57 4.02 4.46 4.80 5.02 5.58
500 2.32 2.90 3.25 3.48 3.72 4.18 4.65 4.99 5.23 5.81
510 2.42 3.02 3.38 3.62 3.87 4.35 4.83 5.20 5.44 6.04
