CYMA CM.702 M24 SWS Spring Sniper Rifle

CYMA
Code: CYM-03-006452-00
144.99
  • Full metal construction
  • 6.03mm Tightbore inner barrel
  • 500 FPS on 0.2g BBs - Right at the limit!

If you fancy trying the sniper playstyle and you are into your military platforms, the CYMA CM.702 M24 should suit you perfectly. This spring bolt action sniper rifle is based on the real steel M24 SWS, the primary sniper rifle of the US Army and many Law Enforcement agencies in the US. The M24 marries the classic bolt action sniper rifle styling with enhancements which set it apart from VSR-10-based rifles, including its M700 style "long action" and its adjustable stock.

The CYMA CM.702 is based on the Classic Army CA/M24 internally and boasts a 6.03mm tightbore inner barrel straight out of the box, hitting out at an impressive 500FPS +/- 10% using 0.2g BBs. Packaged with a 14mm CCW male thread adapter and with a bipod lug and scope rail built-in, the CM.702 is ready to be kitted out with whatever you need to complete your mission!

Full description

Description

If you're looking for an affordable sniper rifle but you prefer things mil-spec, the M24 is the way to go! The CM.702B from CYMA is based on the real steel M24 SWS, the US Army's primary bolt action sniper rifle from 1988 right up until the present day, though modern versions are known as the M2010 ESR.

The M24 is based on the Remington Model 700 in its "long action" form, and as such, the receiver is much bigger than that of comparable bolt action sniper rifles like the VSR-10 which is based on the "short action" version of the M700. This gives the M24 far more presence in the hands ;than a VSR-10 and ideal for those who want a more realistic sniping experience.

The outer barrel of the M24 measures a lengthy 23 inches, giving you a respectable 490mm of inner barrel for increased range and accuracy; exactly what you want from a sniper rifle. The inner barrel is also a 6.03mm tightbore, meaning a slight FPS increase and improved accuracy provided you use high quality BBs.

The CM.702B comes with an unthreaded tip pre-installed on the outer barrel but is packaged with a 14mm CCW male thread adapter. This means you can add a tracer unit, suppressor or flash hider easily by installing the adapter, meaning no messing around looking for rare, specialised adapters when the time comes to upgrade! The adapter simply threads on, replacing your original muzzle cap.

Following the outer barrel rearwards, we come to the chassis/stock of the rifle which is constructed from tough high density polymer with a "bubble" texture effect to improve handling qualities. On the bottom of the chassis, we have a Harris-style bipod/sling stud, ready for a Harris-style bipod to be fitted, followed by another lug with a steel sling loop pre-installed. The front sling point can be paired with the rear sling point on the stock to mount a two-point sling; an especially useful addition if you run your sniper rifle with a sidearm.

Just aft of the sling points, we come to the magazine well which is located in a similar position to that of the VSR-10 sniper rifle, though the M24 uses its own internal system. The magazine catch is built into the front of the magazine itself, making it centrally positioned which is ideal for left or right-handed snipers. Compatibility-wise, the CM.702 accepts M24 magazines from CYMA, Classic Army and Snow Wolf. To the rear of the magazine well we also have a realistic mock magazine, mimicking the real M24 perfectly.

Next up, we reach the receiver which is constructed from alloy, matching the metal to polymer proportions of the real M24 perfectly. Up top, we have a 20mm Picatinny scope rail, ready for your choice of riflescope to be mounted. The rail also has a cutout in the centre, intended to allow spent cases to clear the action in the real thing.

The bolt handle is located on the right side of the rifle and is an extended design with a textured tip for optimal grip. To cock the M24, you will need to lift the bolt, pull it rearward until it locks, push it back forwards and rotate it back into place, just like a real bolt action sniper rifle. The bolt assembly is constructed from alloy and does require some force to cock due to the rather strong 500 FPS spring inside.

The trigger is housed inside the alloy trigger guard assembly and is the standard curved sniper rifle trigger designed to encourage proper finger placement. The trigger pull is nice and short, making it easy to take those accurate long range shots, and the trigger guard is spacious enough to allow all but the thickest gloves to be used.

Behind the trigger guard, we come to what is known as a "Semi-pistol-grip", the traditional gripping location for bolt action rifles. The grip is set at a comfortable angle for shooting both prone and standing, and the bubble texture finish of the stock aids grip so you can keep the rifle firmly in your hands, with or without gloves. The grip of the M24 is wider than comparable VSR-10 grips, making it extra comfortable when shooting from the prone position; the most effective shooting position for snipers.

At the very rear of the M24, we come to the adjustable stock. The stock has a unique and secure method of adjustment, allowing you to set the stock at the perfect length for you. To adjust the stock, simply loosen the smaller locking wheel and then turn the larger adjustment wheel to incrementally extend or retract the stock. Tightening the rearmost wheel will then lock the stock in the desired position.

This is a great improvement over extendable stocks with set positions, as you can make very precise adjustments to either tailor the rifle to your body or adjust based on your stance and position so you've always got the rifle set to exactly what you need in the field. The butt plate at the end of the stock is constructed from rubber with a textured surface, meaning it will stay locked into your shoulder as long as you do your part.

If you are curious about sniping but you want something with a military aesthetic, you can't go wrong with the CYMA CM.702B. This, the Black version, is ideal for those SWAT snipers out there and those who want the classic sniper rifle look. Generously equipped with a 6.03mm tightbore straight out of the box and packing a serious wallop with 500 FPS on a 0.2g BB, all this bad boy needs is a scope!

Features

  • Full metal construction
  • Black finish - Ideally suited to a SWAT or LEO style sniper loadout
  • 14mm CCW Male thread adapter included - Add a suppressor or tracer unit
  • Harris-style sling/bipod mount up front - Add a Harris-style bipod or sling point
  • Wide chassis design - Much wider than VSR-10, matches the real M24 perfectly
  • Sling points front and rear - Swivels attached to Harris-style lugs, steel construction
  • 20mm Picatinny railed receiver - Ready for a red dot sight or sniper scope
  • Two-position manual safety catch - Forward is fire, rearward is safe
  • Adjustable stock - Adjust the length of pull to suit your body type and loadout
  • Compatible with CYMA M24 Magazines | Snow Wolf M24 Magazines - Classic Army CA24/M24 pattern magazines
  • Compatible with upgrade parts for the Classic Army CA/M24 sniper rifle
  • Upgrade kit  - CYMA Upgrade Set for CM.702/M24 Sniper rifle

Package Includes

  • CYMA CM.702 M24 SWS Spring Sniper Rifle; Black
  • 28rnd Magazine
  • Speedloader
  • Thread adapter (14mm CCW)

Specification

General

Weapon Construction External
Weapon Type
Sniper Rifle
Over 18 Only Icon
Over 18
Yes
Icon UKARA - United Kingdom Airsoft Retailer Association
Defence / UKARA Required
Yes, No,
FPS Icon
FPS (Feet Per Second), using 0.20g BB
Approx. 500fps ± 10%, using 0.20g BB
Site Legal Icon
Site Legal, using 0.20g BB
Yes
Screwdriver Icon
Pre-Built
Yes
Package
Included Items
  • Magazine
  • Speed Loader
Skill Level Icon
User Skill Level
Regular Player

Weight and Dimension

Weight KG Icon
Weight (KG)
Approx. 2.83kg
Weapon Length Collapsed
Length (Collapsed)
109cm
Weapon Length Extended
Length (Extended)
117cm

Construction

Colour Wheel Greyscale
Primary Colour
Black
Construction Icon
Construction
Alloy outer barrel, receiver, trigger guard, stock adjustment mech. Steel sling points. High density polymer stock/chassis.
Weapon Construction External
External Construction
Polymer
Alloy
Steel
Gearbox Icon
Internal Construction
Polymer
Alloy
Aluminium
Steel

Weapon Specific

Power Source Icon
Powered By
Spring
Blowback Icon
Blowback
None
Weapon Platform
Sniper Rifle, M24,
Magazine Style Icon
Magazine Style
Long Gun Magazine, Snipers Rifle, M24,
Fire Select Icon
Fire Selector
PatrolBase | Fire Select Safe
Safe
Bolt Action
Fire
Weapon Safety Features Icon
Safety Features
Trigger Lock
Shooter Configuration Icon
Shooter Configuration
Right Handed
Weapon Configuration Icon
Weapon Configuration
Bolt Action
Weapon Scale Icon
Weapon Scale
1:1
Suggested BB Weight
0.25g

Hop-Up

Hop-Up Unit Icon
Hop-Up Unit
Yes
Hop-Up Unit Adjuster Icon
Hop-Up Adjuster
Slider
Hop-Up Unit Location Icon
Hop-Up Location
On the left side of the stock. External slider adjuster

Furniture

Weapon Furniture Icon
Furniture
  • Railed Receiver
  • Harris Bipod Lug
  • Adjustable Stock
  • sling points front and rear
  • 14mm CCW thread adapter
  • Rubber butt plate
Rail System Icon
Rail System
20mm Railed Receiver
Icon Stock Positions
Stock Setting
Adjustable
Sight Type Icon
Sight Type
None
Sling Plate Icon
Sling Options
Stock , Loop ,

Barrel

Outer Barrel Length (in)
23''
Inner Barrel Diameter
6.03mm
Inner Barrel Length
490mm

Magazine Specific

Magazine Type
Sniper Rifle
Magazine BB Capacity
Approx. 28 Rounds
Magazine BB Fill Method
Speed Loader
Magazine BB Fill Location
Top

Product Testing Data

Notepad Icon
Test Description
500 FPS +/- 10%
Notepad Icon
Tested Using
0.2g ASG BLASTER
Notepad Icon
Test Date
08/01/2024

Size guide

Joule Charts

Special Instructions

These table can be used as a reference to see if the BB weight you are using will be over acceptable Joulage limits at some Airsoft Sites in the UK. To check if the weight can be used chrono your weapon using the BB you intend to use, and then compare it to the chart.

FPS, Power and Joule Limits can vary from site to site, so please get in touch with where you're going to play with in advance to avoid disappointment.

Suggested limits are based on Joulage Limit rules used Halo Mill: Proving Grounds, with a 350fps limit for Automatic Replicas, 400fps for Semi-Automatic Replicas, and 500fps for Bolt Action Replicas.

Tap the tabs below to open the relevant chart for your replica.

Suggested limits are based on Joulage Limit rules used Halo Mill: Proving Grounds, and is the equivalent of 350fps, using 0.20g BB resulting in an upper limit of 1.14j.

Velocity BB Weight (Grams)
FPS 0.20 0.25 0.28 0.30 0.32 0.36 0.40 0.43 0.45 0.50
250 0.58 0.73 0.81 0.87 0.93 1.05 1.16 1.25 1.31 1.45
260 0.63 0.79 0.88 0.94 1.00 1.13 1.26 1.35 1.41 1.57
270 0.68 0.85 0.95 1.02 1.08 1.22 1.35 1.46 1.52 1.69
280 0.73 0.91 1.02 1.09 1.17 1.31 1.46 1.57 1.64 1.82
290 0.78 0.98 1.09 1.17 1.25 1.41 1.56 1.68 1.76 1.95
300 0.84 1.05 1.17 1.25 1.34 1.51 1.67 1.80 1.88 2.09
310 0.89 1.12 1.25 1.34 1.43 1.61 1.79 1.92 2.01 2.23
320 0.95 1.19 1.33 1.43 1.52 1.71 1.90 2.05 2.14 2.38
325 0.98 1.23 1.37 1.47 1.57 1.77 1.96 2.11 2.21 2.45
328 1.00 1.25 1.40 1.50 1.60 1.80 2.00 2.15 2.25 2.50
330 1.01 1.26 1.42 1.52 1.62 1.82 2.02 2.18 2.28 2.53
335 1.04 1.30 1.46 1.56 1.67 1.88 2.09 2.24 2.35 2.61
340 1.07 1.34 1.50 1.61 1.72 1.93 2.15 2.31 2.42 2.68
345 1.11 1.38 1.55 1.66 1.77 1.99 2.21 2.38 2.49 2.76
350 1.14 1.42 1.59 1.71 1.82 2.05 2.28 2.45 2.56 2.85
355 1.17 1.46 1.64 1.76 1.87 2.11 2.34 2.52 2.63 2.93
360 1.20 1.51 1.69 1.81 1.93 2.17 2.41 2.59 2.71 3.01

Suggested limits are based on Joulage Limit rules used at Halo Mill: Proving Grounds, and is the equivalent of 400fps, using 0.20g BB resulting in an upper limit of 1.49j.

Velocity BB Weight (Grams)
FPS 0.20 0.25 0.28 0.30 0.32 0.36 0.40 0.43 0.45 0.50
250 0.58 0.73 0.81 0.87 0.93 1.05 1.16 1.25 1.31 1.45
260 0.63 0.79 0.88 0.94 1.00 1.13 1.26 1.35 1.41 1.57
270 0.68 0.85 0.95 1.02 1.08 1.22 1.35 1.46 1.52 1.69
280 0.73 0.91 1.02 1.09 1.17 1.31 1.46 1.57 1.64 1.82
290 0.78 0.98 1.09 1.17 1.25 1.41 1.56 1.68 1.76 1.95
300 0.84 1.05 1.17 1.25 1.34 1.51 1.67 1.80 1.88 2.09
310 0.89 1.12 1.25 1.34 1.43 1.61 1.79 1.92 2.01 2.23
320 0.95 1.19 1.33 1.43 1.52 1.71 1.90 2.05 2.14 2.38
330 1.01 1.26 1.42 1.52 1.62 1.82 2.02 2.18 2.28 2.53
340 1.07 1.34 1.50 1.61 1.72 1.93 2.15 2.31 2.42 2.68
350 1.14 1.42 1.59 1.71 1.82 2.05 2.28 2.45 2.56 2.85
360 1.20 1.51 1.69 1.81 1.93 2.17 2.41 2.59 2.71 3.01
370 1.27 1.59 1.78 1.91 2.03 2.29 2.54 2.73 2.86 3.18
380 1.34 1.68 1.88 2.01 2.15 2.41 2.68 2.88 3.02 3.35
390 1.41 1.77 1.98 2.12 2.26 2.54 2.83 3.04 3.18 3.53
400 1.49 1.86 2.08 2.23 2.38 2.68 2.97 3.20 3.34 3.72
410 1.56 1.95 2.19 2.34 2.50 2.81 3.12 3.36 3.51 3.90

Suggested limits are based on Joulage Limit rules used at Halo Mill: Proving Grounds, and is the equivalent of 500fps, using 0.20g BB resulting in an upper limit of 2.32j.

Velocity BB Weight (Grams)
FPS 0.20 0.25 0.28 0.30 0.32 0.36 0.40 0.43 0.45 0.50
250 0.58 0.73 0.81 0.87 0.93 1.05 1.16 1.25 1.31 1.45
260 0.63 0.79 0.88 0.94 1.00 1.13 1.26 1.35 1.41 1.57
270 0.68 0.85 0.95 1.02 1.08 1.22 1.35 1.46 1.52 1.69
280 0.73 0.91 1.02 1.09 1.17 1.31 1.46 1.57 1.64 1.82
290 0.78 0.98 1.09 1.17 1.25 1.41 1.56 1.68 1.76 1.95
300 0.84 1.05 1.17 1.25 1.34 1.51 1.67 1.80 1.88 2.09
310 0.89 1.12 1.25 1.34 1.43 1.61 1.79 1.92 2.01 2.23
320 0.95 1.19 1.33 1.43 1.52 1.71 1.90 2.05 2.14 2.38
330 1.01 1.26 1.42 1.52 1.62 1.82 2.02 2.18 2.28 2.53
340 1.07 1.34 1.50 1.61 1.72 1.93 2.15 2.31 2.42 2.68
350 1.14 1.42 1.59 1.71 1.82 2.05 2.28 2.45 2.56 2.85
360 1.20 1.51 1.69 1.81 1.93 2.17 2.41 2.59 2.71 3.01
370 1.27 1.59 1.78 1.91 2.03 2.29 2.54 2.73 2.86 3.18
380 1.34 1.68 1.88 2.01 2.15 2.41 2.68 2.88 3.02 3.35
390 1.41 1.77 1.98 2.12 2.26 2.54 2.83 3.04 3.18 3.53
400 1.49 1.86 2.08 2.23 2.38 2.68 2.97 3.20 3.34 3.72
410 1.56 1.95 2.19 2.34 2.50 2.81 3.12 3.36 3.51 3.90
420 1.64 2.05 2.29 2.46 2.62 2.95 3.28 3.52 3.69 4.10
430 1.72 2.15 2.40 2.58 2.75 3.09 3.44 3.69 3.86 4.29
440 1.80 2.25 2.52 2.70 2.88 3.24 3.60 3.87 4.05 4.50
450 1.88 2.35 2.63 2.82 3.01 3.39 3.76 4.04 4.23 4.70
460 1.97 2.46 2.75 2.95 3.15 3.54 3.93 4.23 4.42 4.91
470 2.05 2.57 2.87 3.08 3.28 3.69 4.10 4.41 4.62 5.13
480 2.14 2.68 3.00 3.21 3.42 3.85 4.28 4.60 4.82 5.35
490 2.23 2.79 3.12 3.35 3.57 4.02 4.46 4.80 5.02 5.58
500 2.32 2.90 3.25 3.48 3.72 4.18 4.65 4.99 5.23 5.81
510 2.42 3.02 3.38 3.62 3.87 4.35 4.83 5.20 5.44 6.04
