Double Bell AM.45 Vorpal Bunny GBB Pistol

Double Bell
Code:
3,029.00
  • Full metal 1911 body and slide
  • Custom futuristic furniture
  • Skeletonised hammer and flat trigger

Double Bell brings us a replica of the pistol from the incredibly popular Sword Art Online Alternative Gun Gale, a custom 1911 with souped-up futuristic furniture. The pistol features compensator extensions, which mount to the lower frame, in addition to a flared magazine base plate for that blocky, experimental, anime-style look.

The body and slide of the pistol are constructed from aluminium alloy and sports the classic 1911 design, including serrated grooves on the slide for ease of racking, but with several unique tweaks. With a skeletonised hammer and flat, speed trigger, this pistol is a sure fire hit for those of you looking for that cyber sci-fi and futuristic aesthetic.

Full description

Frequently purchased with this pistol...

Description

Much like the classic 1911, the AM.45's frame and slide are constructed from aluminium alloy, meaning that it still maintains its authentic weight and hefty blowback action. The custom furniture is constructed from lightweight polymer so as to not offset the weight of the tried and tested 1911 form factor.

Sporting classic open ironsights, the AM.45 is for those of you who like a modern style but aim the old-fashioned way with plenty of room for peripheral vision to catch any wily strays in the field.

The AM45 has a smooth grip, with enlarged side panels, which match the front compensator nicely. It features a textured and serrated backstrap for increased ergonomics and a comfortable grip.

The pistol gives you control over your shots via the adjustable gear type HOP unit. To access the HOP, simply remove the slide from the frame, which is achieved by first removing the magazine. Then line up the slide leaver with the smallest cut-out on the slide (pull back the slide until the inner barrel is just visible. Next press the slide release pinion through from the other side. Once the slide release is removed, the slide can be smoothly pushed forward and off the slide rail. Again, the HOP unit is a gear type, adjusted by turning it either up or down. The addition of a HOP allows you to apply backspin to your, making your BBs spin harder as they leave the barrel, helping them stay in the air for longer.

The trigger is similar to the original 1911 design with a few modifications. Much like the hammer, the trigger is of a skeletonised design for a lightweight, more modern design, in addition to being a flat-speed trigger for those of you with an itchy trigger finger! The AM.45 features a trigger lock safety, meaning the trigger cannot be pulled when the rear safety latch is pushed upwards. Adding to the futuristic aesthetic of the pistol, the hammer matches the design of the trigger, being a skeletonised design, which also features a ridged texture on the top to facilitate ease of cocking, for those movie style standoff moments.

Just behind the trigger, we have the textured mag release, which not only has an ultra-modern vibe but is incredibly tactile when activated, while a similar texture can be found on the backstrap of the grip, in keeping with the modern stylings of the pistol, which means that, combined with the side panels makes this pistol fantastic to hold and shoot. Another modern feature of the AM45 is in the left side panel, which boasts a thumb indentation for a really ergonomic grip and really helps in bridging the gap between the backstrap and the mag release.

The pistol comes included with an 18-round green gas-powered magazine with an interesting modification. The magazine base plate sports a flared extrusion, which is in keeping with the rest of the pistol's aesthetic but also aids in ergonomics and grip as your little finger is held firmly in place against this plate for a more comfortable grip and sturdy aim.

So if you're looking for a unique take on a classic pistol with a futuristic twist, or maybe you're just a fan of Sword Art Online Alternative Gun Gale, this Double Bell is a great offering that features that all-important gas blowback, with alloy body and slide, augmented with custom and unique furniture to stand out in the skirmish.

Features

  • Gas Blowback Pistol
  • 1911 Platform Replica
  • Alloy Slide & Frame
  • Custom futuristic furniture
  • Skeletonised hammer
  • Skeletonised flat trigger
  • Trigger lock safety
  • Green gas powered
  • 18rnd magazine
  • Ergonomic thumb groove
  • Flared magazine baseplate
  • Angled slide serrations for friction
  • Textured backstrap
  • Supplied in a hard storage/transport case
  • Spare magazines available here

Package Includes

  • Double Bell AM.45 Vorpal Bunny GBB Pistol
  • 18rnd Green Gas Magazine
  • User manual

Specification

General

Weapon Construction External
Weapon Type
Pistol
Over 18 Only Icon
Over 18
Yes
Icon UKARA - United Kingdom Airsoft Retailer Association
Defence / UKARA Required
Yes, No,
FPS Icon
FPS (Feet Per Second), using 0.20g BB
Approx. 250fps ± 10%, using 0.20g BB
Site Legal Icon
Site Legal, using 0.20g BB
Yes
Screwdriver Icon
Pre-Built
Yes
Package
Included Items
Magazine
Skill Level Icon
User Skill Level
Starter

Weight and Dimension

Weight KG Icon
Weight (KG)
Approx. 0.825kg
Weapon Length Collapsed
Length (Collapsed)
18.5cm
Weapon Length Extended
Length (Extended)
21cm

Construction

Colour Wheel Greyscale
Primary Colour
Black, Pink,
Two Tone Icon
Pre Two-Toned
No, Yes,
Construction Icon
Construction
Alloy body and slide with polymer furniture
Weapon Construction External
External Construction
Polymer
Alloy
Gearbox Icon
Internal Construction
Polymer
Alloy
Aluminium
Steel

Weapon Specific

Power Source Icon
Powered By
Green Gas
Blowback Icon
Blowback
Gas Blowback
Weapon Platform
Pistol, 1911,
Magazine Style Icon
Magazine Style
Pistol Magazine, 1911,
Fire Select Icon
Fire Selector
PatrolBase | Fire Select Safe
Safe
Patrol Base | Fire Select - Semi Automatic
Semi Automatic
Weapon Safety Features Icon
Safety Features
Trigger Lock
Shooter Configuration Icon
Shooter Configuration
Right Handed
Weapon Configuration Icon
Weapon Configuration
Standard
Internal Variants
Standard Gears
Standard Gears
Weapon Scale Icon
Weapon Scale
1:1
Suggested BB Weight
0.2g

Hop-Up

Hop-Up Unit Icon
Hop-Up Unit
Yes
Hop-Up Unit Location Icon
Hop-Up Location
Removing the slide reveals the HOP adjuster in the middle of the underside

Furniture

Rail System Icon
Rail System
None
Sight Type Icon
Sight Type
Iron Sights , Open Iron Sight,

Barrel

Outer Barrel Length (in)
3.5''
Inner Barrel Diameter
6.03mm

Magazine Specific

Magazine Type
Gas
Magazine BB Capacity
Approx. 18 Rounds
Magazine BB Fill Method
Speed Loader
Magazine BB Fill Location
Front
Magazine Gas Fill Location
Bottom
Magazine Gas Type
Green Gas

Pistol Specific

Construction Icon
Slide Material
Alloy
Icon Pistol Slide
Pistol Slide Type
Standard

Product Testing Data

Notepad Icon
Test Description
250FPS +/- 10%
Notepad Icon
Tested Using
ASG Blaster 0.2g
Notepad Icon
Test Date
24/05/2023

Size guide

Joule Charts

Special Instructions

These table can be used as a reference to see if the BB weight you are using will be over acceptable Joulage limits at some Airsoft Sites in the UK. To check if the weight can be used chrono your weapon using the BB you intend to use, and then compare it to the chart.

FPS, Power and Joule Limits can vary from site to site, so please get in touch with where you're going to play with in advance to avoid disappointment.

Suggested limits are based on Joulage Limit rules used Halo Mill: Proving Grounds, with a 350fps limit for Automatic Replicas, 400fps for Semi-Automatic Replicas, and 500fps for Bolt Action Replicas.

Tap the tabs below to open the relevant chart for your replica.

Suggested limits are based on Joulage Limit rules used Halo Mill: Proving Grounds, and is the equivalent of 350fps, using 0.20g BB resulting in an upper limit of 1.14j.

Velocity BB Weight (Grams)
FPS 0.20 0.25 0.28 0.30 0.32 0.36 0.40 0.43 0.45 0.50
250 0.58 0.73 0.81 0.87 0.93 1.05 1.16 1.25 1.31 1.45
260 0.63 0.79 0.88 0.94 1.00 1.13 1.26 1.35 1.41 1.57
270 0.68 0.85 0.95 1.02 1.08 1.22 1.35 1.46 1.52 1.69
280 0.73 0.91 1.02 1.09 1.17 1.31 1.46 1.57 1.64 1.82
290 0.78 0.98 1.09 1.17 1.25 1.41 1.56 1.68 1.76 1.95
300 0.84 1.05 1.17 1.25 1.34 1.51 1.67 1.80 1.88 2.09
310 0.89 1.12 1.25 1.34 1.43 1.61 1.79 1.92 2.01 2.23
320 0.95 1.19 1.33 1.43 1.52 1.71 1.90 2.05 2.14 2.38
325 0.98 1.23 1.37 1.47 1.57 1.77 1.96 2.11 2.21 2.45
328 1.00 1.25 1.40 1.50 1.60 1.80 2.00 2.15 2.25 2.50
330 1.01 1.26 1.42 1.52 1.62 1.82 2.02 2.18 2.28 2.53
335 1.04 1.30 1.46 1.56 1.67 1.88 2.09 2.24 2.35 2.61
340 1.07 1.34 1.50 1.61 1.72 1.93 2.15 2.31 2.42 2.68
345 1.11 1.38 1.55 1.66 1.77 1.99 2.21 2.38 2.49 2.76
350 1.14 1.42 1.59 1.71 1.82 2.05 2.28 2.45 2.56 2.85
355 1.17 1.46 1.64 1.76 1.87 2.11 2.34 2.52 2.63 2.93
360 1.20 1.51 1.69 1.81 1.93 2.17 2.41 2.59 2.71 3.01

Suggested limits are based on Joulage Limit rules used at Halo Mill: Proving Grounds, and is the equivalent of 400fps, using 0.20g BB resulting in an upper limit of 1.49j.

Velocity BB Weight (Grams)
FPS 0.20 0.25 0.28 0.30 0.32 0.36 0.40 0.43 0.45 0.50
250 0.58 0.73 0.81 0.87 0.93 1.05 1.16 1.25 1.31 1.45
260 0.63 0.79 0.88 0.94 1.00 1.13 1.26 1.35 1.41 1.57
270 0.68 0.85 0.95 1.02 1.08 1.22 1.35 1.46 1.52 1.69
280 0.73 0.91 1.02 1.09 1.17 1.31 1.46 1.57 1.64 1.82
290 0.78 0.98 1.09 1.17 1.25 1.41 1.56 1.68 1.76 1.95
300 0.84 1.05 1.17 1.25 1.34 1.51 1.67 1.80 1.88 2.09
310 0.89 1.12 1.25 1.34 1.43 1.61 1.79 1.92 2.01 2.23
320 0.95 1.19 1.33 1.43 1.52 1.71 1.90 2.05 2.14 2.38
330 1.01 1.26 1.42 1.52 1.62 1.82 2.02 2.18 2.28 2.53
340 1.07 1.34 1.50 1.61 1.72 1.93 2.15 2.31 2.42 2.68
350 1.14 1.42 1.59 1.71 1.82 2.05 2.28 2.45 2.56 2.85
360 1.20 1.51 1.69 1.81 1.93 2.17 2.41 2.59 2.71 3.01
370 1.27 1.59 1.78 1.91 2.03 2.29 2.54 2.73 2.86 3.18
380 1.34 1.68 1.88 2.01 2.15 2.41 2.68 2.88 3.02 3.35
390 1.41 1.77 1.98 2.12 2.26 2.54 2.83 3.04 3.18 3.53
400 1.49 1.86 2.08 2.23 2.38 2.68 2.97 3.20 3.34 3.72
410 1.56 1.95 2.19 2.34 2.50 2.81 3.12 3.36 3.51 3.90

Suggested limits are based on Joulage Limit rules used at Halo Mill: Proving Grounds, and is the equivalent of 500fps, using 0.20g BB resulting in an upper limit of 2.32j.

Velocity BB Weight (Grams)
FPS 0.20 0.25 0.28 0.30 0.32 0.36 0.40 0.43 0.45 0.50
250 0.58 0.73 0.81 0.87 0.93 1.05 1.16 1.25 1.31 1.45
260 0.63 0.79 0.88 0.94 1.00 1.13 1.26 1.35 1.41 1.57
270 0.68 0.85 0.95 1.02 1.08 1.22 1.35 1.46 1.52 1.69
280 0.73 0.91 1.02 1.09 1.17 1.31 1.46 1.57 1.64 1.82
290 0.78 0.98 1.09 1.17 1.25 1.41 1.56 1.68 1.76 1.95
300 0.84 1.05 1.17 1.25 1.34 1.51 1.67 1.80 1.88 2.09
310 0.89 1.12 1.25 1.34 1.43 1.61 1.79 1.92 2.01 2.23
320 0.95 1.19 1.33 1.43 1.52 1.71 1.90 2.05 2.14 2.38
330 1.01 1.26 1.42 1.52 1.62 1.82 2.02 2.18 2.28 2.53
340 1.07 1.34 1.50 1.61 1.72 1.93 2.15 2.31 2.42 2.68
350 1.14 1.42 1.59 1.71 1.82 2.05 2.28 2.45 2.56 2.85
360 1.20 1.51 1.69 1.81 1.93 2.17 2.41 2.59 2.71 3.01
370 1.27 1.59 1.78 1.91 2.03 2.29 2.54 2.73 2.86 3.18
380 1.34 1.68 1.88 2.01 2.15 2.41 2.68 2.88 3.02 3.35
390 1.41 1.77 1.98 2.12 2.26 2.54 2.83 3.04 3.18 3.53
400 1.49 1.86 2.08 2.23 2.38 2.68 2.97 3.20 3.34 3.72
410 1.56 1.95 2.19 2.34 2.50 2.81 3.12 3.36 3.51 3.90
420 1.64 2.05 2.29 2.46 2.62 2.95 3.28 3.52 3.69 4.10
430 1.72 2.15 2.40 2.58 2.75 3.09 3.44 3.69 3.86 4.29
440 1.80 2.25 2.52 2.70 2.88 3.24 3.60 3.87 4.05 4.50
450 1.88 2.35 2.63 2.82 3.01 3.39 3.76 4.04 4.23 4.70
460 1.97 2.46 2.75 2.95 3.15 3.54 3.93 4.23 4.42 4.91
470 2.05 2.57 2.87 3.08 3.28 3.69 4.10 4.41 4.62 5.13
480 2.14 2.68 3.00 3.21 3.42 3.85 4.28 4.60 4.82 5.35
490 2.23 2.79 3.12 3.35 3.57 4.02 4.46 4.80 5.02 5.58
500 2.32 2.90 3.25 3.48 3.72 4.18 4.65 4.99 5.23 5.81
510 2.42 3.02 3.38 3.62 3.87 4.35 4.83 5.20 5.44 6.04
